Zepoxy 800

Zepoxy 800 is an adhesive and coating material suitable for areas with high dampness, specially recommended for river and sea-water exposure. Zepoxy 800 can be easily used on wood, metal, and concrete.

Clear
Add to wishlist
Category

    Zepoxy 800 is an adhesive and coating material suitable for areas with high dampness, specially recommended for river and sea-water exposure. Zepoxy 800 can be easily used on wood, metal, and concrete.

    TECHNICAL DATA

    Property Test Method Result
    Appearance Part A Visual Low viscosity, clear liquid
    Appearance Part B Visual Low viscosity, light yellow liquid
    Mix ratio (Part A: Part B) Theoretical 100: 56
    *Mix viscosity @ 25°C ASTM D 2196 800 – 500 cPs
    *Flash Point ASTM D 93 >117°C
    *Coverage per kg Theoretical 9 SFT @ 1mm thick
    Recommended maximum casting thickness – 5mm
    *Pot life (300g mix) @ 25°C – 15 min
    *Gel time @ 25°C (1mm thickness) – 1h 44m
    *Hardening time – 16 hours
    *Full Cure – 7 days
    *Flexural Strength (MPa) ASTM D 790 77.0
    *Compressive Strength (MPa) ASTM D 695 88.0

    These are typical results under laboratory conditions.

    NOTE

    It is a quick curing system so application should be planned accordingly.

    MIXING

    The mixing ratio must be accurately followed to achieve perfect results. It is not possible to change the ratio which would result in the epoxy not drying properly and lower mechanical properties. Pour the hardener first and then the resin. The mixed components should be thoroughly mixed for 3-4 minutes to ensure an even consistency. To avoid development of bubbles slowly mix for 5-10 mins. Once the epoxy is mixed and poured gently pass warm air from a heat gun or hair dryer on slowest speed setting, this will assist in removal of any bubbles generated during mixing.

    PAKAGING

    Zepoxy 800 is available as follows:

    1.56 KG Set              Part A: 1KG
    Part BL 560g

    HEALTH AND SAFETY

    Dispose containers of the materials as per local laws, rules, and regulations. Use gloves, safety masks and other safety apparel as per health and safety laws. For further assistance, please refer to the MSDS of the product for further health and safety information.

    Packaging

    1 KG, 1.2 KG, 1.23 KG, 1.25 KG, 1.4 KG, 1.5 KG, 1.54 KG, 1.56 KG, 1.6 KG, 1.8 KG, 2 KG, 2.17 KG, 2.18 KG, 2.5 KG, 3.2 KG, 3.8 KG, 5 KG, 10 KG, 12 KG, 14 KG, 15 KG, 15.4 KG, 16 KG, 18 KG, 20 KG, 21.7 KG, 21.8 KG, 22.5 KG, 24 KG, 24.25 KG, 24.6 KG, 25 KG, 27 KG, 28 KG, 30 KG, 30.8 KG, 38 KG, 42 KG, 45 KG, 50 KG, 54 KG, 200 KG, 230 KG, 1000 KG, 1 Ltr, 5 Ltr, 10 Ltr, 15 Ltr, 30 Ltr, 200 Ltr, 1000 Ltr
Technical Datasheet
Product Description
Zepoxy Tabletop Deep Pour is a retarded clear epoxy casting system, which offers a long open time for precise article placement and complete bubble removal. It has inbuilt UV inhibitors as well as excellent visual properties. It also avoids high exothermic reaction and the resulting shrinkage after curing.
Zepoxy 800 is an adhesive and coating material suitable for areas with high dampness, specially recommended for river and sea-water exposure. Zepoxy 800 can be easily used on wood, metal, and concrete.

TECHNICAL DATA

Property Test Method Result
Appearance Part A Visual Low viscosity, clear liquid
Appearance Part B Visual Low viscosity, light yellow liquid
Mix ratio (Part A: Part B) Theoretical 100: 56
*Mix viscosity @ 25°C ASTM D 2196 800 – 500 cPs
*Flash Point ASTM D 93 >117°C
*Coverage per kg Theoretical 9 SFT @ 1mm thick
Recommended maximum casting thickness - 5mm
*Pot life (300g mix) @ 25°C - 15 min
*Gel time @ 25°C (1mm thickness) - 1h 44m
*Hardening time - 16 hours
*Full Cure - 7 days
*Flexural Strength (MPa) ASTM D 790 77.0
*Compressive Strength (MPa) ASTM D 695 88.0
These are typical results under laboratory conditions.

NOTE

It is a quick curing system so application should be planned accordingly.

MIXING

The mixing ratio must be accurately followed to achieve perfect results. It is not possible to change the ratio which would result in the epoxy not drying properly and lower mechanical properties. Pour the hardener first and then the resin. The mixed components should be thoroughly mixed for 3-4 minutes to ensure an even consistency. To avoid development of bubbles slowly mix for 5-10 mins. Once the epoxy is mixed and poured gently pass warm air from a heat gun or hair dryer on slowest speed setting, this will assist in removal of any bubbles generated during mixing.

PAKAGING

Zepoxy 800 is available as follows: 1.56 KG Set              Part A: 1KG Part BL 560g

HEALTH AND SAFETY

Dispose containers of the materials as per local laws, rules, and regulations. Use gloves, safety masks and other safety apparel as per health and safety laws. For further assistance, please refer to the MSDS of the product for further health and safety information.
