Zepoxy LEEG 10

Zepoxy LEEG-10 is a solvent free, three component, free flow epoxy grout designed for mass grouting. Due to its low exothermic reaction, it is particularly suitable for grouting at high ambient temperatures. Zepoxy LEEG-10 can be used for grouting heavy machinery base plates, compressors, generators, turbines, centrifugal pumps, bolt pockets, Crain rails, bridge bearing, stanchion (Steel column) base plates reprofiling-waterproofing of pile and areas where rotary / reciprocator movements are encountered. It is used as a grout media to transfer dynamic load effectively. Ideal for chemical plants, refinery, oil and gas, water industry and structural encasing.

Add to wishlist

    Zepoxy LEEG-10 is a solvent free, three component, free flow epoxy grout designed for mass grouting. Due to its low exothermic reaction, it is particularly suitable for grouting at high ambient temperatures. Zepoxy LEEG-10 can be used for grouting heavy machinery base plates, compressors, generators, turbines, centrifugal pumps, bolt pockets, Crain rails, bridge bearing, stanchion (Steel column) base plates reprofiling-waterproofing of pile and areas where rotary / reciprocator movements are encountered. It is used as a grout media to transfer dynamic load effectively. Ideal for chemical plants, refinery, oil and gas, water industry and structural encasing.

    ADVANTAGES

    • Prepacked, ready to use.
    • Solvent free, no shrinkage.
    • High mechanical strength.
    • Can be used for 30mm to 300mm in a single layer without
    • generating excessive exotherm.
    • Curing is not affected by high humidity.
    • Impact and vibration resistant.
    • Good chemical resistance.
    • Good adhesion to most of the surfaces.

    SURFACE PREPARATION

    All surfaces should be dry, clean, free from standing water, grease, curing compounds, mold oils and all loosely adhering particles. Cement laitance should be removed by mechanical means. Roughen surface with chipping to ensure good bonding. Steel surfaces must be clean and rust free.

    MIXING

    Mix base and hardener roughly with a slow speed drill (Max 400 rpm) for 1 minute in a suitable container. Add filler component slowly and continue mixing until a flowing uniform color is achieved.

    FORMWORK

    The formwork should be watertight. Sealant can be used to seal gaps between formwork and the concrete, as well as joints in the formwork. Alternatively, a suitable plugging material can be used to fill the gap between formwork and concrete.

    TYPICAL PROPERTIES AT 25°C

    Property

    Test Method

    Value

    Component

    Three:

    Part A – Base

    Part B – Hardener

    Part C – Filler

    Mixed Form

    Flowable Paste

    Color

    Grey when mixed

    Mixed Density

    2.1 kg/ltr +/- 0.05

    Compressive Strength

    BS 6319-2

    3 Days

    50 N/mm2

    7 Days

    95 N/mm2

    Flexural Strength

    BS 6319-3

    7 Days

    30 N/mm2

    Tensile Strength

    BS 6319-7

    7 Days

    15 N/mm2

    Bond Strength

    ASTM D 4541

    7 Days

    >2.5 N/mm2

    Pot Life

    100-120 mins (2 KG Mixed Material)

    Chemical Resistance

    ASTM D 543

    Resistant to alkalis, fuels, acids, oils, etc.

    Typical Results under laboratory conditions

    APPLICATION

    Place the mixed grout within the pot life of the product. Bolt pockets should be glued first. Stop the grout 5mm to 10mm below the top surface of the bolt pocket. Grouting of the base plate should be carried out continuously. Ensure to have enough grout in place prior to starting. Start pouring the mixed grout from one side of the formwork to prevent entrapping of air. This can be achieved by pouring the grout to the shortest distance. During application ensure entrapped air is released through relief holes. Maintain continuous head during the grouting. Grout flow should be interrupted. Check for any grout loss through the form work or between unsealed joints. Plug the same using a suitable water plug. For difficult voids a metal strap or chains may be used to assist grout flow.

    NOTE

    Zepoxy LEEG-10 can be applied from 30mm to 300mm thickness in a single layer. Grouting more then 300mm thickness would be done in multiple layers as per site requirement. Before continuing with the second layer of grouting, ensure the previous layer has hardened and cooled.

    SHILE LIFE AND CLEANING

    12 months from date of manufacturing when stored under warehouse conditions in original unopened packing. Extreme temperature / humidity may reduce shelf life. Clean all equipment and tools with a suitable cleaner immediately.

    HEALTH AND SAFETY

    Gloves goggles and suitable masks mist be worn. Contact with skin, eyes, etc. must be avoided. If swallowed seek medical attention immediately. This material is regarded as nonhazardous for transportation. Do not reuse containers. To be disposed as per local rules and regulations. Refer to product MSDS for further information.
