Zepoxy 100 y
Zepoxy 100Y is an all-purpose epoxy adhesive useful for bonding of materials such as metal, wood,
ceramic, concrete, textile, glass, leather, etc. Its long pot life and non-corrosive nature combined with
its high level of curing and hardness development.
Zepoxy 100Y is an all-purpose epoxy adhesive useful for bonding of materials such as metal, wood, ceramic, concrete, textile, glass, leather, etc. Its long pot life and non-corrosive nature combined with its high level of curing and hardness development even in low temperature, humid environments make this epoxy adhesive an extremely versatile material for a variety of applications. This system has the additional benefit of a light-colored hardener and a 2-year shelf life.
TECHNICAL DATA
| Property |
Test Method |
Result |
| Appearance Part A |
Visual |
Medium viscosity, yellowish liquid |
| Appearance Part B |
Visual |
Medium viscosity, Dark Brownish to red liquid |
| Mix ratio (Part A: Part B) |
Theoretical |
100: 80 |
| *Mix viscosity @ 25°C |
ASTM D 2196 |
8000 – 15000 cPs |
| *Flash Point |
ASTM D 93 |
>135°C |
| *Pot life (300g mix) @ 25°C |
- |
30 – 70 min |
| *Hardening time |
- |
24 hours |
| *Full Cure |
- |
7 days |
*Typical results under laboratory conditions.
CURED SYSTEM PROPERTIES
| Property |
Test Method |
7 days |
2h@80°C |
| *Flexural Strength |
ASTM D 790 |
69 MPa |
60 MPa |
| Compressive Strength - Ultimate |
ASTM D 695 |
85 MPa |
150 MPa |
*Typical results under laboratory conditions.
NOTE:
At 40°C gel time will be reduced to half, in case of increased temperatures, pouring should be planned accordingly.
PACKAGING
Zepoxy 100Y is available as follows:
Mini set 180g Part A: 100g Part B: 80g
Half Set 900g Part A: 500g Part B: 400g
Full Set 1.8 KG Part A 1 KG Part B: 800g
Commercial Pack 54 KG Part A: 30 KG Part B: 24 KG
HEALTH AND SAFETY
Dispose containers of the materials as per local laws, rules, and regulations. Use gloves, safety masks and other safety apparel as per health and safety laws. For further assistance, please refer to the MSDS of the product for further health and safety information.
